• ready for use boron nitride coating for standard applications

• for aluminium, magnesium, zinc and lead

• yields non-wetting, lubricating surfaces

• for ladles, troughs, dies, thermocouples, ingot moulds

• contains "white graphite"

Description

ALU-STOP LC5 Boron-Nitride-Coating is a ready for use special coating for the non-ferrous metal casting and contains boron nitride as a refractory filler. Thus ALU-STOP LC5 Boron-Nitride-Coating shows a good non-wetting behaviour against Al, Mg, Zn and Pb as well as their alloys. It is an ideal high temperature release and lubrication agent for the coating of ladles, troughs, distribution troughs, moulds and protects these efficiently against attacks by aggressive melts. For highest performance the concentrates ALU-STOP LC25 Boron-Nitride-Coating and ALU-STOP LC15 Boron-Nitride-Coating are available. During fewer high demands the ready for use suspension ALU-STOP LC10 Boron-Nitride-Coating is used.

Application

• Resuspend coating prior to use and dilute with distilled water if necessary.

• Application on clean surfaces is possible by painting or spraying. Best results may be achieved by spraying onto warm surfaces (50-150°C, 122-302°F).

• Dry thoroughly. Do not contact wet coatings with metal melts. Additional layers may be applied after drying.

• Best performance of ALU-STOP LC5 Boron-Nitride-Coating is achieved by thin coatings (up to 50-150µm). Thick coatings may crack during use.

• Do not damage coating during use because damaged areas are not sufficiently protected.

• Tools may be cleaned with water.

Storage-Container Size

ALU-STOP LC5 Boron-Nitride-Coating must be protected against frost. A storage temperature of >5°C (>41°F) is recommended. The containers should be kept closed. ALU-STOP LC5 Boron-Nitride-Coating is available in 6kg-containers.

Technical Data
Colour	white
Ceramic Constituent	Boron Nitride
Binder	Alumina
Solid Content (Boron Nitride)	5%
Density	1,05 g/cm³
Temperature (max. Application)	1000°C (at air)
	1800°C (under inert gas)



---

© 2023 Büro für angewandte Mineralogie · Dr. Stephan Rudolph · D-47918 Tönisvorst

---

These recommendations are believed to be correct. However, no guarantee of their accuracy is given. Therefore, purchasers shall make their own tests to determine suitability for their use. These products are offered for industrial and related uses (e.g. research and development) only. However the user must take the necessary precautions appropriate for products containing chemicals. This description does not imply the absence of any patents, the responsibility whatsoever solely rests with the user.
